C96900 Copper Nickel Tin Alloy (CONTINUOUS CAST)

C96900 Copper Nickel Tin Alloy (CONTINUOUS CAST)

Copper Nickel Tin Alloy CX is alloy C96900 Nickel Bronze that is spinodally hardened to pick up properties exceeding those regularly found in other high strength copper alloys. This Copper-Nickel-Tin Alloy has properties like Copper Beryllium Alloys.

C96900 Copper Nickel Tin Alloy (CONTINUOUS CAST)

A non-magnetic alloy , it is thermally solidified by means of spinodal decomposition, a proven heat treatment process. Copper Nickel Tin Alloy CX continuous cast and spinodally hardened condition show tensile up to 120 ksi and hardness up to HRC 34. For a copper alloy comprising of Copper - 15% Nickel - 8% Tin, this alloy sustains a high level of machinability. In spite of the fact that this procedure has been around for nearly as long as precipitation solidifying has been for Copper-Beryllium, current upgrades in spinodal deterioration have given this combination to be matured to a considerably higher quality level—now close to Copper Beryllium, without the beryllium.

To get in touch with us, contact us right now. Our sales personnel are always available for providing their services. Place your order right now!

C96900 Copper Nickel Tin Alloy (CONTINUOUS CAST) Specifications:

Style
Temper
Size Diameter inches
Tensile Strength Ksi (Mpa)
Yield Strength 0.05% UL Ksi (Mpa)
Elong%
Hardness Strength RC
Rod
CX 105
1.5 - 4.0
110 (758)
105 (723)
4 Min
30
Tube
CX 105
1.5 - 4.0
110 (758)
105 (723)
4 Min
30
CX 105
>4.0 - 15.0
99 (682)
94.5 (651)
4 Min
40

C96900 Copper Nickel Tin Alloy (CONTINUOUS CAST) CHEMICAL COMPOSITION :

CU
NI+CO
SN
MG
MN
FE
PB
ZN
NB
Remainder.
14.5 - 15.5
7.5 - 8.5
0.15 Max
0.3 Max
0.5 Max
0.02 Max
0.5 Max
0.1 Max

C96900 Copper Nickel Tin Alloy (CONTINUOUS CAST) MECHANICAL PROPERTIES:

Coefficient of Thermal Expansion Ppm/°F
8.9 - 9.1 x 106
Density
0.325
Electrical Conductivity % IACS
6 - 10
Electrical Resistivity µΩcm
16.7 - 25
Modulas of Elasticity in Tension
18.4 Ksi (126 Mpa)
Melting Point Solid US
2,040°F (1,115°C)
Melting Point Liquid US
1,742°F (940°C)
Magnetic Permeability
< 1.001
Thermal Conductivity W/m °K
28.0

C72900 Copper Nickel Tin Alloy (CONTINUOUS CAST):

All
ASTM-B-505
SLB CMS-Z69GJ.0
SLB 400822
Sperry Sun 600061A
Nace MRO 175
ENOVATE EN-SPEC 00091
EXPRO MS-1312
FMC M401032
BMS 7-373
SLB 400822
